(Attachment will vary depending on product. Text limited to 2 lines of 25 characters each, max.)

specify increasing or decreasing pressure or temperature and set points. (three switch versions only)

pressure connection(s) only, sensor material cannot be changed - Differential pressure versions 12K only

1/2” NPT male x 1/8” NPT female

1/4” NPT(M)

Junction box, pre-wired, with (2) 3/4” electrical connections. Not approved for enclosure type 4X

conforms to DIN 43650 (not approved for Class 1, Div 1 & 2 or CENELEC flame proof requirements)

Viton construction (deadbands and low end of range may increase; Wetted parts include Viton diaphragm and O-ring plus standard connection material unless noted). Refer to datasheet for details.

Cleaned in accordance with ASTM G93, Verification Type I, Tests 1 through 3

10% net value/unit

15% net value/unit

converts 7/8” hole to 1/2” NPT fitting

1/4" NPT female

1/2" NPT female

7/16-20 SAE
