117 Series Pressure Switch (H117 Models 520-525)

https://www.doger.com/web/image/product.template/10746/image_1920?unique=98894ad

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

H117 - One SPDT output; epoxy coated enclosure; internal adjustment with “High-Low” reference scale.

Buna N diaphragm and O-ring with epoxy coated aluminum 1/2” NPT (female) pressure connection; large 0.72” orifice for clean-out purposes

  • Pressure parameters .

Esta combinación no existe.

United Electric Controls
Interruptores de presion, interruptores de temperatura, Termocuplas, RTDs, transmisores de temperatura y presioón, detección de gases

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Pressure Switch (H117 Models 520-525)

Pressure parameters . 520 - Set Point Range: 300 Vac to 0 “wc /Deadband: 0.8 to 32 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi or 521 - Set Point Range: 10 Vac to 10 “wc /Deadband: 0.4 to 2.4 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi or 522 - Set Point Range: 50 Vac to 50 “wc /Deadband: 0.4 to 12 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi or 523 - Set Point Range: 0.4 to 1.2 “wc /Deadband: 0.8 to 32 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi or 524 - Set Point Range: 2.5 to 50 “wc /Deadband: 0.4 to 3.2 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi or 525 - Set Point Range: 10 to 250 “wc /Deadband: 0.4 to 24 “wc /Over Range Pressure : 100 psi/ Proof Pressure: 100 psi
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors
