117 Series Pressure Switch (H117 Models 483-489 )

https://www.doger.com/web/image/product.template/10751/image_1920?unique=5ff801f

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

H117 - One SPDT output; epoxy coated enclosure; internal adjustment with “High-Low” reference scale.

316L stainless steel diaphragm (optional HastelloyR C or MonelR); VitonR GLT O-ring (optional KalrezR, Ethylene Propylene, or AflasR); 316 stainless steel 1/2” NPT (female) pressure connection (optional HastelloyR C or MonelR), large 0.72” orifice for clean-out purposes. Models 188 and 189 have a 316L stainless steel 1/2” NPT (female) pressure connection; NACE MR 0175 compliant.

  • Pressure parameters .

Esta combinación no existe.

United Electric Controls
Interruptores de presion, interruptores de temperatura, Termocuplas, RTDs, transmisores de temperatura y presioón, detección de gases

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Pressure Switch (H117 Models 483-489 )

Pressure parameters . 483 - Set Point Range: 1 to 20 psi /Deadband: 0.3 to 5 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 484 - Set Point Range: 2 to 50 psi /Deadband: 0.3 to 10 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 485 - Set Point Range: 4 to 100 psi /Deadband: 0.5 to 16 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 486 - Set Point Range: 8 to 200 psi /Deadband: 0.5 to 21.5 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 488 - Set Point Range: 50 to 1000psi /Deadband: 30 to 300 psi /Over Range Pressure : 2000 psi / Proof Pressure: 7000 psi or 489 - Set Point Range: 250 to 3500 psi /Deadband: 50 to 500 psi /Over Range Pressure : 4000 psi / Proof Pressure: 7000 psi
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors
